SELGEM: The Logical Structure

This is the second of a three-part-series on SELGEM, a pioneering computer system used to manage museum collections in the United States. Read the first post here.

A SELGEM (an acronym for: SELf GEnerating Master) computer record was what we all define as a typical record, all the information about: one object, one specimen, one work of art, one publication, or, one person, etc. It included all the related fields or data elements. The SELGEM logical record was composed of one or more physical records. A logical record was all the “physical records” with identical Serial Numbers.

Because SELGEM was a general purpose data management system it was used for a wide range of applications at the Smithsonian Institution. Computer applications (using SELGEM) in the 1970s included: museum objects from National Museum of Natural History (NMNH), National Museum of American History (NMAH), National Air and Space Museum (NASM), art museums, the Smithsonian Institution Archives, Volcanoes of the World, bibliographic applications, systematic checklists, type-specimen catalogs, Catalog of American Portraits, National Portrait Gallery (NPG), Inventories of American Painting and Sculpture, and a list of threatened and endangered plants in the United States. Many of these pioneer applications continue today, having evolved into modern databases and web-based applications.

SELGEM master file, directory record
Ayensu, Edward S. and Robert A. DeFilipps. 1978.  Endangered and threatened plants of the United States.  xv, 403 pages.  Smithsonian Institution, Washington, DC.
Typically a SELGEM logical record was composed of from about 5 to 50 physical records (individual lines); maybe an occasional application included as many as a hundred. The Category Numbers could be any number between “001” and “999”. Each Category Number represented a data element. The first Category Number for a logical record was not required to begin with “001” and application owners generally provided gaps when assigning Category Numbers to create a more flexible design. However a Master List of records displayed Category Numbers, and the associated data, in numerical sequence.

The first line of a category always began with Line Number “01”. If the amount of data exceeded 64 characters, then continuation lines were created, and numbered sequentially “02”, “03”, etc. The theoretical maximum amount of data for one data element (or Category) was 99 lines x 64 characters or a maximum of 6,336 characters.
Sample SELGEM record, page III
Creighton, Reginald A., Penelope Packard, and Holley Linn.  1971.  SELGEM Retrieval:  a general description.  Smithsonian Institution Procedures in Computer Sciences, 1(1):(6 pages) + 1-38.Dated July 1972.
The theoretical maximum amount of data for one logical record was: 999 Category Numbers x 6,336 characters, for a total of 6,329,664 (or 6.3 megabytes). No application reached this size, let alone an individual record. In addition, individual SELGEM computer programs also had memory limits; which also limited the maximum size of a record that could be processed. Remember, even mainframe computers had some limitations.

Some advantages of this design:
  • Easy to add new data elements to any SELGEM record by creating new catalog numbers (Either due to lack of planning or the development of data elements, such as DNA information.)
  • Empty, missing, or blank data elements were not stored in the SELGEM record
  • Flexibility to respond to changing and evolving user requirements
  • The data structure was under the control and responsibility of the end user and less restricted by the application, and
  • With limited technical support staff, a general purpose system supported more applications across the organization than if custom-design systems were developed for each application.
A sample page of a master list showing six logical records
Wilson, Don E., Beth Ann Sabo, and Gregory Blair.  1987.  Automated Data Processing Procedures at the U.S. National Museum of Natural History, pages 111-119.  In:  Genoways, Hugh H., Clyde Jones, and Olga L. Rossolimo (editors).  Mammal Collection Management.  Texas Tech University Press
All the stored data was character data; there was no ability to store binary data, special numerical data types, image data, memo fields, currency or “date formatted” information, as are typically supported in many current database programs. Most application owners in NMNH maintained a detailed data standards document external to SELGEM; defining the data definition, data format, controlled vocabulary lists, and rules for recording the data, etc.

David Bridge, Volunteer

Wednesday, July 20, 2016

SELGEM: The Data Structure

This is the first of a three-part-series on SELGEM, a pioneering computer system used to manage museum collections in the United States

The first publication about the Smithsonian’s
SELGEM system, August 1971.
SELGEM was an information management computer system invented, developed, and distributed at the Smithsonian Institution and used for more than 30 years.  The exact invention date for SELGEM has been lost to antiquity, perhaps very late 1969; however Reginald A. Creighton and James J. Crockett, two of the men who developed and created SELGEM, state that it “has been in operation … since spring 1970”.*  SELGEM has been called a “records management system”, rather than a true database, at least in the modern senses of the word.  In an era pre-dating relational databases, when commercial software tools were almost nonexistent, SELGEM was used to organize and manage data in a wide variety of applications at the Smithsonian and also many other institutions.  The name is an acronym derived from the system’s full name:  SELf GEnerating Master.  It was “self-generating” because of its general purpose format and because no initial computer programming was required to create a new data file or application.


The SELGEM data structure was simple.
User documentation illustrating the relationship between SELGEM transactions records and SELGEM master records.  Undated, ca. 1971-1972, MNH.
The physical record was a single fixed length record of 77 characters in length. There were only four components to the record:
Serial Number, 8 characters, required, no spaces, an alphanumeric value. Frequently it was a number, however, it could be an arbitrary number, but it could also be a data element**, such as a museum catalog number, a sample number, or a photo image number.
Category Number, three digit numeric, required.  Any three digit number could be used, between “001” and “999”.  The Category Number was a code number for a data element* or data field name.
Line Number, two digits numeric, in the range of “01” to “99”, required.  The first Line Number for a Category Number should begin with “01” and continuation lines should be numbered sequentially.
Data:  the good stuff, up to 64 characters of data could be stored in a single SELGEM line or a physical record.
A single physical record frequently represented a single data element if the data were less than 64 characters in length, or one line of multi-line textual data element, such as:  remarks, description, or an abstract. As an example, suppose that data element “Country” has been assigned to Category Number “100”, the data fits into one line, and the record would look like this:
1234567810001United States





The computer records were created by the SELGEM update program (SELUPD) from a sorted SELGEM transaction record file.  SELGEM transaction records were 80 characters in size (see flowchart at right).  The transaction code controlled the action to be performed by the update program, such as add, change, or delete.






SELGEM transaction records could be prepared using any data entry technology available.

Forms used to create data entry programs on the key-to-disk systems

The 80-character IBM card format could be produced directly or indirectly.  The following technologies were used for data entry at the Smithsonian at various times:  paper type typewriters, teletype machines, IBM keypunches, key-to-disk data entry systems (such as ENTREX and NIXDORF systems), optical characters recognition (OCR), optical mark sense (OMR) forms, and personal computers.







This was the SELGEM physical record description; in the next blog the story will continue with the Logical Record structure.  A Logical Record was all the “physical records” with identical Serial Numbers (the first eight characters).

David Bridge, Volunteer
Smithsonian Institution Archives

*Creighton, Reginald A. and James J. Crockett.  1971.  SELGEM:  A system for collection management.  Smithsonian Institution Information Systems Innovations 2(3):1.

**The term data element is used as defined in wikipedia.org:  “the term data element is an atomic unit of data that has precise meaning or precise semantics.”  https://en.wikipedia.org/wiki/Data_elementIn SELGEM only the 3-digit code number was stored in the computer file; the definition, data standards, rules, and attributes were defined externally to SELGEM.
